IP Video Input : 32 channels

Max. Resolution : 3840 × 2160 (4K / 8 MP)

Frame Rate : 30 fps

Video Compression : H.265 / H.264, Smart codec support

Display Split : 1 / 4 / 9 / 16 / 32

Recording Modes : Continuous, Manual, Event

Pre/Post-Event Recording : Main stream 2 Mbps, sub stream 1 Mbps; Post-event 30 seconds (max. 60 seconds)

Simultaneous Playback Channel Count : 16 channels

Decoding Capability : H.265/H.264 3840 × 2160 @ 30 fps (1 channel) or 1920 × 1080 @ 120 fps (4 channels)

Playback Functions : Play, Pause, Stop, Reverse play, Next frame, 30 seconds back/forward, Speed control, Timeline, Digital zoom, Snapshot, Backup

Search Modes : Time search, Event search, Video clip

Snapshot Format : JPG

Recording Data Stream : max. 320 Mbps

Max Incoming Bandwidth : 400 Mbps

Max Outgoing Bandwidth : 400 Mbps

HDMI / VGA Output : HDMI x2, VGA x1; simultaneous output on three ports supported; supported resolutions: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768

Audio Input / Output : 3.5 mm line input x1 / 3.5 mm line output x1

Audio Format : G.711

Two-Way Communication : Supported

Network Interface : 10/100/1000 Mbps Ethernet (RJ-45) x 2

Protocols : IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP (secure), DNS, DDNS, IP Filter, P2P, SNMP

ONVIF : ONVIF Profile S

Maximum Users : 16

P2P : Supported with global P2P service TUTK

USB Ports : Front: 2 × USB 2.0; Rear: 1 × USB 3.0

Keyboard and Mouse : Supported via USB ports

Mobile and Browser Support : iOS 11 or later, Android 5.0 or later; Browsers: Edge, Chrome, Firefox, Safari

SATA Bay : 8 × 3.5″ SATA

Supported Capacity : Max. 10 TB per disk; Total max. 80 TB (8 × 10 TB)

RAID Support : RAID 1 / 5 / 6

Backup : Manual backup with USB flash drive (FAT format)

eSATA : Supported

N+1 Redundancy : Supported (max. N = 10)

Processor : ARM processor

Operating System : Embedded Linux

User Management : Administrator and normal user levels

Log : Recording, User

Date and Time : Time zone, Manual, Automatic NTP synchronization, Daylight saving time

PTZ Operations : Direction control, Home position, Iris, Preset, Patrol (group), Sharpness +/-, Zoom +/-

Alarm Input Channels : 16

Alarm Output Relay Channels : 6

Alarm Events : Camera alarm input, Motion detection, Camera disconnection, Tampering detection

Event Actions : Video recording, Email sending, Buzzer, FTP, Camera alarm output, PTZ preset, System alarm output, Send video to full screen

RS-485 : Supported

RS-232 : Supported

Stream Encryption : Hardware-embedded encryption chip with integrated cryptographic keys

Command Encryption : Supported between NVR and web client/viewer/mobile app

TPM : Provides end-to-end encryption

HTTPS : Supported

Secure Boot : Supported (with Honeywell cybersecurity standards)

PCI-DSS Compliance : Supported

Secure NTP : Supported

NDAA Section 889 : Designed for compliance

Power Supply : 100-240 V AC, 50/60 Hz (single SMPS)

Power Consumption : max. 200 W; 15 W without HDD

Dimensions : 440 × 426 × 100 mm (17.32″ × 16.77″ × 3.94″)

Weight : 7 kg (15.43 lb)

Rack Height : 2.2 U

Operating Temperature : -10°C ~ 55°C (14°F ~ 131°F)

Storage Temperature : -40°C ~ 60°C (-40°F ~ 140°F)

Relative Humidity : Less than 90%

Fan : Yes

Certifications : FCC Part 15; CE: EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-6-4, EN 50130-4, EN 55035, EN 62368-1, EN 63000; UL: UL/CSA 62368-1; ICES-003; UKCA; RCM; RoHS: CE (EN 63000), UAE (Cabinet Decree No. 10 of 2017)
