CAME-ÖZAK SUPER FROG Swing Gate Operator (Underground, Max. Leaf Length 8 m / Max. Leaf Weight 1500 kg, 230/400 V AC three-phase)
Special quotes and installation support for project and bulk purchases. Get a project quote
CAME-ÖZAK SUPER FROG
The SUPER FROG underground swing gate operator runs on a 230/400 V AC three-phase supply and is designed for special applications; it is suitable for leaves up to 8 m long and weighing up to 1500 kg.
Underground Installation
Designed for underground mounting with an underground box.
High Capacity
Maximum leaf length is specified as 8 m and maximum leaf weight as 1500 kg (weight decreases with length: 4 m / 1200 kg, 5 m / 1000 kg, 6 m / 800 kg, 7 m / 700 kg, 8 m / 600 kg).
Power and Motor
Has 600 W motor power, 230/400 V AC three-phase supply and 2.5 A max. current draw.
Durability and Operating Conditions
Offers IP67 protection, an operating temperature range of -20 °C to +55 °C and a 50 % duty cycle.
Technical Specifications
Mounting Type (Surface / Underground) : With underground box
Maximum Gate/Leaf Weight : 1500 kg (decreases with length: 4 m / 1200 kg, 5 m / 1000 kg, 6 m / 800 kg, 7 m / 700 kg, 8 m / 600 kg)
Maximum Gate/Leaf Length : 8 m
Power Supply : 230/400 V AC three-phase
Motor Power : 600 W
Current Draw : 2.5 A max.
Torque : 1000 Nm
Opening Time : For 90°: 45 s
Opening Angle : 95°
Protection Class (IP) : IP67
Operating Temperature Range : -20 °C to +55 °C
Duty Cycle : 50 %
Variants / Order Codes
001FROG-MD : FROG-MD – Right gearmotor, 230/400 V AC three-phase, max. leaf length 8 m, max. leaf weight 600 kg
001FROG-MS : FROG-MS – Left gearmotor, 230/400 V AC three-phase, max. leaf length 8 m, max. leaf weight 600 kg
