CAME-ÖZAK FROG PLUS Swing Gate Operator (Underground, 5.5–7 m / 550–700 kg depending on model, 230 V AC)
Special quotes and installation support for project and bulk purchases. Get a project quote
CAME-ÖZAK FROG PLUS
A 230 V swing gate operator with an underground box; designed for heavy leaves, the series has a maximum capacity of 7 m and 1000 kg. Different model variants (FROG-PM4, FROG-PM6) are available.
Underground mounting
Suitable for an underground box mounting structure and designed for underground installation.
Model variants and capacity
Series max. 7 m and 1000 kg; FROG-PM4: 5.5 m / 700 kg; FROG-PM6: 7 m / 550 kg.
Power and torque
Has 500 W motor power, 2.1 A current and 800 Nm torque.
Control and safety
Includes an encoder, adjustable mechanical limit switches and an automatic re-engagement system.
Technical Specifications
Mounting Type (Surface / Underground) : Underground (with underground box)
Maximum Gate/Leaf Weight : Series max. 1000 kg; FROG-PM4: 700 kg; FROG-PM6: 550 kg
Maximum Gate/Leaf Length : Series max. 7 m; FROG-PM4: 5.5 m; FROG-PM6: 7 m
Power Supply : 230 V AC
Motor Power : 500 W
Current Draw : 2.1 A
Torque : 800 Nm
Opening Time : For 90°: FROG-PM4: 30 s; FROG-PM6: 45 s
Protection Class (IP) : IP67
Operating Temperature Range : -20°C to +55°C
Cycles per Hour : FROG-PM4: 10 cycles/hour; FROG-PM6: 6 cycles/hour
Variants / Order Codes
001FROG-PM4 : FROG-PM4 – 230 V AC, max. leaf length 5.5 m, max. leaf weight 700 kg
001FROG-PM6 : FROG-PM6 – 230 V AC, max. leaf length 7 m, max. leaf weight 550 kg
